TEL 3895-120916-V1 Printed Circuit Board

TEL 3895-120916-V1 Printed Circuit Board

 Introduction

TEL 3895-120916-V1 Printed Circuit Board

Adapt to TEL etching and thin film deposition semiconductor equipment, control multiple MFC gas flow signals

Multi layer high-density wiring, analog digital signal partition routing, reducing signal crosstalk interference

Surface technology of sinking gold on the board, oxidation resistance of solder pads, stable contact for long-term use in dust-free workshops

Low exhaust clean grade substrate, suitable for wafer dust-free production chamber conditions without pollutant precipitation

Large area inner copper shielding to resist RF plasma and electromagnetic interference from frequency converters

Built in multi-channel sampling and voltage stabilization branch, accurately collecting flow and pressure sensing data

Independent circuit current limiting protection, single channel failure will not cause the entire board to shut down

Optimize the layout of thermal conductive vias, ensure stable temperature rise control during continuous operation of power components

Standard gold finger slot structure, direct insertion and disassembly of equipment cabinets, easy replacement and maintenance

Accurate impedance matching routing, distortion free and drift free transmission of weak flow signals

Strengthen the PCB substrate and solder joints, making them less prone to detachment during equipment vibration and platform movement

Clear silk screen component numbers and locations, quick troubleshooting and locating of circuits

Industrial wide temperature board, without deformation or layering in high and low temperature environments around the cavity

Original factory full load power on aging detection, directly compatible with TEL process equipment of the same series

Compact integrated board layout, suitable for small module installation space inside the device

TEL 3895-120916-V1 printed circuit board has precise signal acquisition and strong anti-interference, and is a spare part for semiconductor gas flow control dedicated core board

Product imag
