YASKAWA XU-BCD2081D Robot Controller Module

YASKAWA XU-BCD2081D Robot Controller Module

Product Details Introduction

YASKAWA XU-BCD2081D Controller Module (AMAT equipment matching, part number 0190-14741)

1. Yaskawa linear motor drive main control, matched application materials Endura PVD coating machine wafer handling manipulator

2. Built in dedicated motion processing chip, closed-loop control of linear axis, micrometer level precision completion of silicon wafer transfer and placement

3. Multi channel encoder interface, real-time acquisition of linear motor position and speed feedback signals, closed-loop correction of displacement deviation

4. Isolation type IO terminal, connected to on-site sensing components such as vacuum detection, chamber door interlocking, and gas source switch

5. Panel partition fault indicator light, power supply, bus communication, overload fault partition display, quick troubleshooting of fault points

6. Integrated protection against overcurrent, overvoltage, overheating, and static electricity, suitable for voltage fluctuations in semiconductor factory power grids

7. Onboard EMI filtering circuit to isolate RF interference from the cavity, avoiding step loss and coordinate deviation during the operation of the robotic arm

8. The circuit board is fully coated with three anti coatings to meet the requirements of low dust, constant temperature and closed process environments in dust-free workshops

9. Industrial gold-plated interface terminals, earthquake resistant and oxidation resistant, maintain stable electrical connections during high-frequency reciprocating operation of equipment

10. Built in power-off storage chip, motion trajectory and speed parameters are saved after power-off, and there is no need to reset parameters when restarting

11. Built in dynamic adaptive gain algorithm, automatically adjusts output with small load changes, reducing on-site debugging time

12. Standard industrial communication port, can be connected to the upper computer of the equipment, realizing program download and remote monitoring of running status

13. The whole machine cabinet has a vertical installation structure, with snap on disassembly and assembly, and is compatible with XU series drive spare parts that can be replaced

14. Wide temperature industrial component selection, dust-free room operates continuously and stably at full load 24/7 from 20 ℃ to 30 ℃

15. Original factory aging calibration, compatible with AMAT coating equipment cavity, can be put into wafer mass production process after installation

YASKAWA XU-BCD2081D is the core control unit of semiconductor PVD equipment wafer transfer linear motor

Product imag
