NI SCXI-1163R Digital Output Module
NI SCXI-1163R Digital Output Module
Product Details Introduction
NI SCXI-1163R is a 32 channel solid-state relay digital output module launched by National Instruments in the United States, mainly used for low-speed digital signal control and switching high-voltage circuits.
Main parameters:
Number of channels: 32 output channels
Relay type: Solid state relay, Form A (normally open)
Maximum switching voltage: 240 V (AC or DC)
Maximum switching current: 200 mA (per channel)
Isolation voltage between channels: 450 V (between channel groups or between channel groups to ground)
Leakage current: maximum about 1 μ A (typical value)
Conduction time: approximately 1.5 milliseconds
Disconnecting time: approximately 0.25 milliseconds
Connector type: Use standard DIN 48 pin connector
Working temperature range: 0 to 50 degrees Celsius
characteristic:
No mechanical components, long service life
High channel density, suitable for batch control applications
Optoelectronic isolation design enhances the system's anti-interference capability
Suitable for voltage switching scenarios that do not require high switching speed
Application areas:
Automatic Test System (ATE)
Industrial control
Remote voltage switching
Switch control of high-voltage equipment in data acquisition system
Product imag
