Jeol AP002282-00 scans the generator module

Jeol AP002282-00 scans the generator module

Product Introduction

Jeol AP002282-00 scans the generator module

Product Features

1. Designed specifically for JEOL scanning electron microscopy, it outputs scanning drive waveforms and controls the scanning trajectory of the electron beam grating.

2. Supports switching between multiple scanning rates, enabling full screen scanning, line scanning, and fixed-point beam spot modes.

3. The waveform output has high stability, reduces scanning distortion, and ensures the geometric accuracy of microscopic images.

4. Built in synchronous signal output, achieving precise alignment of electron beam scanning and image acquisition timing.

5. Compatible with JEOL electron microscope host slots, can be replaced directly, and the installation and debugging process is simple.

Product application areas

1. Scanning electron microscope SEM electron beam scanning driving unit

2. Field emission scanning electron microscope grating signal generation module

3. Semiconductor wafer defect detection electron microscope scanning control component

4. Observation of material microstructure using electron microscopy scanning signal source

5. Analysis of metal fracture failure using electron microscope main control scanning unit

6. Electron microscopy equipment for micro area composition analysis of mineral samples

7. Maintenance spare parts for SEM instruments in university material laboratories

8. Industrial quality inspection scanning electron microscope maintenance and replacement project

9. Transformation of image scanning system for micro characterization equipment in research institutes

10. The JEOL series scanning electron microscope is equipped with a scanning control module for the entire machine

This module is a spare part for the core scanning signal of JEOL scanning electron microscope, which generates electron beam deflection drive signals, controls the electron beam to scan and image the sample surface, and ensures stable acquisition of electron microscope images.

Product imag
