Jeol AP002127 (01) Communication Module

Jeol AP002127 (01) Communication Module

Product Introduction

Jeol AP002127 (01) Communication Module

Product Features

1. Suitable for dedicated data exchange of scanning electron microscope host, high-speed transmission of images and control instructions, with low communication delay.

2. The board is manufactured with precision technology and has strong resistance to electromagnetic interference, ensuring stable communication in vacuum equipment environments.

3. Standard slot type installation structure, easy to replace, can quickly complete instrument spare parts replacement and maintenance.

Application Fields

1. Jeol Scanning Electron Microscope System

2. Semiconductor CD-SEM measurement equipment

3. Material analysis electron microscope host control system

4. Precision electronic optical detection instruments

5. Micro nano morphology observation and analysis equipment

6. High end material characterization equipment in the laboratory

7. Wafer defect detection electron microscope device

8. Nanostructured observation and research equipment

9. Microscopic analysis instruments for metal materials

10. Microelectronics Device Testing and Analysis System

Product Specifications

1. Dedicated parallel bus interface to achieve high-speed data exchange between the host and the daughter board.

2. Operating temperature range of 0-50 ℃, suitable for the internal working environment of the electron microscope cabinet.

3. Onboard signal verification circuit with communication anomaly recognition and feedback function.

The Jeol AP002127 (01) communication module serves as the core communication board for the electron microscope, responsible for transmitting internal instructions and image data to ensure the stable operation of the entire scanning electron microscope system.

Product imag
