Product Introduction

Matrox XMI02 Y7291-02 XMI02/24/5000 acquisition card is a multi-channel high-definition audio and video acquisition and output board of Maichuang, responsible for multi-channel SDI video and audio signal acquisition, processing and forwarding, ensuring real-time transmission of broadcast level images.

Product Features

Supports synchronous collection of multiple audio and video channels, with low image transmission delay.

Onboard hardware image processing engine, capable of real-time image scaling and synthesis.

Integrated audio and video synchronization mechanism, stable alignment of audio and image timing.

The PCI interface is compatible with industrial control hosts and has good driver compatibility.

Equipped with fault bypass protection, it ensures continuous signal output in case of abnormalities.

Product application areas

Matrox XMI02 series video system is used in conjunction with it.

Multi channel video signal processing in broadcasting and television studios.

Real time image synthesis equipment for virtual studio.

Medical imaging system video capture unit.

Industrial machine vision high-definition image acquisition platform.

Multi channel signal access component for live recording equipment.

High definition signal acquisition for traffic video surveillance system.

Research imaging recording and image analysis equipment.

Automated visual inspection video processing unit.

Repair and replacement of spare parts for audio and video workstations.

Product Specifications

Compatible models: Matrox XMI02 series audio and video processing system.

Function: Multi channel SDI audio and video signal acquisition, real-time processing, and output.

Applicable scenario: Long term continuous signal processing operations for industrial control workers in computer rooms.

Matrox XMI02 Y7291-02 XMI02/24/5000 acquisition card is a core board for real-time audio and video processing, used for professional image equipment maintenance and replacement.

Product imag
