DSPACE GmbH DS1103-11 Controller Board

DSPACE GmbH DS1103-11 Controller Board

Product Introduction

The dSPACE GmbH DS1103-11 controller board is a dSPACE real-time simulation control board used for rapid prototyping and hardware in the loop testing to ensure real-time computation and signal interaction

Product Features

Fast real-time computing speed supports fast operation of control models

Integrate multiple ADDA digital IO interfaces for flexible signal acquisition and output

Adapt to MATLAB/Simulink modeling, development, debugging, and convenience

Equipped with CAN bus interface for easy integration with various controlled devices

Real time status monitoring facilitates rapid location of experimental faults

Product application areas

DSPACE real-time simulation system is used in conjunction with

Prototype development of new energy motor control

Automotive powertrain hardware in the loop testing

Automated servo control algorithm verification

Robot motion control experimental platform

Simulation testing of power electronic converters

University Automation Research Experiment Project

Simulation verification of aircraft control system

Development and testing of engine electronic control strategy

Repair and replacement of spare parts for simulation equipment

Product Specifications

Compatible with dSPACE DS1103 series real-time simulation system

Real time model operation signal acquisition and output

Applicable scenarios for laboratory research and development testing tasks

DSPACE GmbH DS1103-11 controller board is a real-time simulation core board used for scientific research and testing equipment maintenance and replacement

Product imag
