Keithley 6517-142-04D Printed Circuit Board

Keithley 6517-142-04D Printed Circuit Board

Product Introduction

Keithley 6517-142-04D printed circuit board is a supporting motherboard for Keithley 6517 electrostatic meter, responsible for weak electrical signal processing to ensure high-precision electrical measurement stability

Product Features

Strong weak signal processing ability and high measurement accuracy

Low noise circuit reduces external electromagnetic interference

Compatible with Keithley 6517 electrostatic meter for stable communication

Precision board with small temperature drift suitable for long-term laboratory testing

Built in status feedback facilitates instrument troubleshooting

Product application areas

Keithley6517 Electrometer for use with matching

Semiconductor leakage current detection experiment

High resistance material resistivity test

Electrical performance testing of photovoltaic cells

Insulation performance testing of dielectric materials

Measurement of weak electrical signals in university laboratories

Material charge characteristic analysis equipment

Electrical characterization testing of thin film devices

Research precision electrical testing platform

Maintenance and replacement of spare parts for precision testing instruments

Product Specifications

Compatible with Keithley 6517 series electrostatic meter

Functional weak current voltage signal processing

Applicable scenarios: Laboratory constant temperature precision measurement operations

Keithley 6517-142-04D printed circuit board is a core spare part for precision electrical testing instruments used for scientific research equipment maintenance and replacement

Product imag
