Jenaer 34S42-0560-B05PB-08 servo motor

Jenaer 34S42-0560-B05PB-08 servo motor

Product Introduction

Jenaer 34S42-0560-B05PB-08 servo motor is a German Jenaer ECOSTEP series closed-loop servo motor used for precision linear rotation positioning, outputting smooth torque to adapt to high-precision automation equipment

Product Features

Closed loop feedback control, low-speed operation without jitter, high positioning accuracy

Multi pole winding design, capable of outputting sustained high torque in a small volume

Built in encoder provides real-time feedback on rotor position, with fast response speed

Sturdy body structure, shock resistant and compatible for continuous operation of equipment

Standardized flange installation facilitates equipment assembly and spare parts replacement

Application Fields

Semiconductor packaging equipment positioning driver unit

Precision detection platform motion execution motor

Laser microfabrication equipment feed axis drive

Servo power components for electronic component assembly equipment

Precision displacement mechanism for optical instruments

Small feed axis device for precision machine tools

Laboratory automation positioning platform

Micro precision conveying equipment

Printing precision registration drive mechanism

Medical automation precision motion equipment

Product Specifications

DC 150V power supply, compatible with dedicated servo drives

The equipment cabinet operates stably in the regular temperature range for a long time

Integrated built-in encoder, real-time feedback of position signal

Jenaer 34S42-0560-B05PB-08 servo motor, as a precision positioning power spare part, relies on closed-loop control to achieve high-precision action output, and is commonly used for semiconductor and various precision automation equipment maintenance and replacement

Product imag
