TEL 5044-000230-11 Controller Board

TEL 5044-000230-11 Controller Board

Product Introduction

TEL 5044-000230-11 Controller Board

Product Features

High speed parallel signal processing capability adapted for real-time process control of semiconductor cavities

Multi channel analog-to-digital signal acquisition and conversion support sensor signal acquisition and processing

Onboard signal isolation protection to resist complex electromagnetic interference in vacuum chambers

The standard slot type board structure facilitates quick disassembly and replacement inside the equipment

Built in fault diagnosis self-test function reports real-time abnormal information of signal channels

Product application areas

Semiconductor etching equipment cavity control system

Equipment for wafer thin film deposition process

Main control unit of plasma processing equipment

Vacuum process chamber signal acquisition system

Motion control module for wafer transfer mechanism

Gas flow ratio linkage control system

Semiconductor heat treatment process equipment

Clean process equipment signal interaction unit

200mm 300mm wafer process platform

Semiconductor equipment safety interlock monitoring system

Product Specifications

Signal interface with multiple analog and digital I/O channels

Power Supply Specification: Onboard DC Industrial Power Supply

Installation method: Equipment chassis slot assembly

The TEL 5044-000230-11 controller board, as the core control board of Tokyo Electronic Semiconductor Equipment, is responsible for cavity sensor signal acquisition and process action scheduling to ensure the stable operation of the wafer manufacturing process.
