JDSU DSAM-6300 frequency scanning cable measuring instrument

JDSU DSAM-6300 frequency scanning cable measuring instrument

Product Introduction

The JDSU DSAM-6300 frequency scanning cable measuring instrument is a JDSU handheld HFC hybrid fiber coaxial network comprehensive frequency scanning testing instrument, used for spectrum scanning and digital service detection of the forward and reverse links of cable TV broadband networks.

Product Features:

1. Equipped with Stealth Sweep invisible frequency scanning technology, online frequency scanning does not interfere with existing business signals.

2. Supports DOCSIS 3.0 multi-channel binding testing, which can detect broadband, voice, and video services.

3. Integrate spectrum analysis, QAM signal analysis, MER and BER error measurement.

4. Sturdy dust-proof and waterproof shell, visible screen under strong outdoor light, suitable for on-site operation and maintenance.

5. Built in gigabit Ethernet port, capable of testing network indicators such as IP throughput, jitter, and packet loss.

Application fields:

6. Radio and television HFC coaxial network link sweep maintenance.

7. Cable TV digital signal quality testing.

8. Troubleshooting of broadband cable modem network faults.

9. Bidirectional network feedback channel noise and intrusion testing.

10. Debugging and acceptance of front-end equipment in the broadcasting and television room.

11. Acceptance of broadband entry into residential areas.

12. Detection of MOS value for VoIP voice service quality.

13. Fiber coaxial hybrid network renovation project.

14. Replacement of instrument spare parts for communication operation and maintenance site.

15. Radio and television network amplifier and node debugging and calibration.

Product Parameters:

16. Test function: forward and reverse frequency scanning, spectrum QAM、DOCSIS3.0。

17. Interface: RF port+Gigabit Ethernet port.

18. Power supply: Equipped with a built-in lithium battery, it supports long-term outdoor work.

JDSU DSAM-6300 sweeping cable measuring instrument is a comprehensive testing instrument for on-site operation and maintenance of HFC networks in broadcasting and television, providing one-stop diagnosis of RF and broadband business faults
