Agilent DSO1024A oscilloscope

Agilent DSO1024A oscilloscope

Product Introduction

The Agilent DSO1024A oscilloscope is a portable 4-channel digital oscilloscope from Agilent, used for electronic signal acquisition, observation, and waveform analysis.

Product Features:

1. 200MHz bandwidth, 4 analog channels, capable of synchronously collecting multiple signals.

2. High sampling rate and strong ability to capture transient signals.

3. Comes with FFT waveform calculation and 23 automatic measurement functions.

4. 5.7-inch color LCD screen, with intuitive and clear waveform display.

5. Support template testing to facilitate batch detection and judgment of waveform quality.

Application fields:

6. Electronic research and development circuit debugging.

7. Laboratory teaching experiments in universities.

8. Performance testing of power products.

9. Embedded hardware signal detection.

10. Maintenance of automotive electronic circuits.

11. Industrial control board testing.

12. Communication basic signal analysis.

13. Maintenance of consumer electronics products.

14. Basic investigation of electromagnetic interference.

15. Electronic production line quality inspection station.

Product Parameters:

16. Bandwidth: 200MHz, 4 analog channels.

17. Maximum sampling rate: 2GSa/s.

18. Storage depth: 10kpts per channel.

The Agilent DSO1024A oscilloscope is portable, easy to use, and has stable performance. It is a commonly used signal testing instrument for electronic research and maintenance.

Product imag
