Schlumberger IXD7232-25 Single Board Computer

Schlumberger IXD7232-25 Single Board Computer

Product Introduction

Schlumberger IXD7232-25 is a dedicated single board computer for Schlumberger logging equipment, responsible for downhole instrument data acquisition, computation, and communication transmission.

Product application areas

Main control of downhole logging equipment for oil drilling

Cable logging instrument data processing unit

Oil and gas well formation parameter acquisition system

Electric control assembly of offshore oilfield logging equipment

Analysis of downhole imaging logging signals

Drilling real-time monitoring terminal control

Replacement of spare parts for oilfield exploration instruments

High temperature underground detection equipment computing unit

Oil and gas well casing testing instrument

Underground multi-sensor data collection and processing

Product Features

Reinforced integrated veneer design, resistant to high temperature and pressure underground

Real time collection and processing of multi-channel sensor signals underground

Built in hardware fault self check, abnormal status reporting

Anti strong vibration and electromagnetic interference, suitable for harsh underground working conditions

Onboard high-capacity flash memory for storing geological survey data

Product Specifications

Support wide range DC power supply

Integrated multi-channel analog digital acquisition channels

Adapt to the installation of internal slots in logging instruments

This single board computer is reliable in computing and ensures stable acquisition and transmission of downhole logging data. Schlumberger IXD7232-25 is the core computing board of oil and gas exploration logging instruments

Product imag
