LAM 810-073479-005 Communication Module

LAM 810-073479-005 Communication Module

Product Introduction

LAM 810-073479-005 is the gas box motherboard of the Panlin etching equipment, responsible for gas path signal acquisition and overall communication interaction.

Product Features

1. Multi channel digital and analog signal acquisition, stable acquisition

2. Channel isolation to resist electromagnetic interference in the workshop

3. On board self check, quickly identify channel faults

4. Slot style installation, with original card components directly replaced

5. Suitable for long-term mass production and operation in vacuum clean workshops

Application Fields

1. Communication for the main control of the gas box of the Panlin etching equipment

2. Semiconductor cavity process signal transmission

3. Data exchange of wafer etching machine

4. Gas control signal processing for plasma process equipment

5. Maintenance and replacement of LAM equipment card failure

6. Gas path signal acquisition for thin film deposition equipment

7. Communication support for plasma cleaning machine

8. Renovation of old semiconductor etching equipment

9. Display panel process equipment signal control

10. Data collection of vacuum process equipment

LAM 810-073479-005 is responsible for the signal and communication transmission of the machine's air box, and is the core board of the Panlin etching equipment

Product imag
