Kistler 9257A Three way Force Gauge

Kistler 9257A Three way Force Gauge

Product Introduction

Kistler 9257A Three way Force Gauge

This Kistler 9257A triaxial force gauge adopts piezoelectric quartz sensing technology, which can simultaneously collect dynamic cutting forces in X, Y, and Z directions

Product Features

Three axis synchronous force measurement with fast response speed and high stiffness

Equipped with insulation structure to avoid interference from ground loops

Waterproof, anti coolant splash, suitable for machining environment

Extremely small force deformation does not affect machining accuracy

Scalable calculation of torque for six component measurement

Application Areas

Milling, drilling, turning, cutting force testing

Research on Grinding Processing Technology

Precision tool performance test

Analysis of Cutting Performance of New Materials

University Mechanical Research Experiment Platform

Aviation component processing and testing

Optimization of mold processing technology

Automotive parts cutting test

Material impact mechanics testing

Process calibration testing of processing equipment

Kistler 9257A triaxial force gauge can be used for various dynamic cutting force measurement scenarios to accurately capture the changes in triaxial force during the machining process

Product imag
