 Introduction

SCA SCHUCKER 90160.005006 Control Panel

This SCA SCHUCKER 90160.005006 is a SYS6000MC system operation keyboard panel used on adhesive equipment for parameter settings and device status retrieval.

SCA adhesive system dedicated human-machine operation panel

Integrated small display screen, function keys, and numeric keypad, with key switch included

Communicate and interact with the SYS6000 main control unit through a dedicated bus

Support input and modification of process parameters such as adhesive quantity, pressure, and speed

The panel adopts embedded installation, and the front can resist a small amount of oil stains and splashes in the workshop

The selection must verify the complete part number, as panels of the same series with different numbers cannot be interchanged

Turn off the power of the entire machine before disassembly and maintenance to avoid static electricity damage to the communication port

Before installation, check the communication cables, test the button input and screen display functions

Idle storage should be protected against dust to prevent oil accumulation and aging of key contacts

Application

Automobile production line glue coating equipment human-machine operation matching

Automated glue control cabinet maintenance and replacement

Vehicle body sealing and adhesive system parameter debugging unit

Improvement of the operation interface of industrial quantitative gluing equipment

Replacement of spare parts for SYS6000 series adhesive coating equipment

SCA SCHUCKER 90160.005006 control panel enables editing of adhesive process parameters, viewing of equipment start stop and fault information.
