LEYBOLD TURBOTRONIK NT151/361 Turbopump Controller

LEYBOLD TURBOTRONIK NT151/361 Turbopump Controller

 Introduction

LEYBOLD TURBOTRONIK NT151/361 Turbopump Controller

This LEYBOLD TURBOTRONIK NT151/361 is a variable frequency drive unit for Leybold turbo molecular pumps, specifically designed to drive the TURBOVAC151 and 361 series molecular pumps, controlling pump body acceleration, stable speed operation, and fault monitoring.

Laibao High Vacuum Equipment Dedicated Variable Frequency Controller

Convert single-phase mains power into three-phase drive power to supply the turbo pump motor

Equipped with multiple status indicator lights, it intuitively displays power on, acceleration, normal, and fault status

Built in current monitoring and overload protection, triggering an alarm when the front-end pressure is abnormal

Supports local button start stop and can also be remotely controlled through external terminals

Suitable for desktop placement or 19 inch rack embedded installation methods

Model selection must be verified, and different specifications of turbo pump controllers cannot be mixed

Cut off the power supply before maintenance, wait for the internal capacitor to fully discharge before disassembling and assembling

Before starting the machine, check the connection line of the pump body and confirm the linkage logic of the vacuum pre stage pump

Long term storage should be kept dry and ventilated to avoid moisture and corrosion of the circuit board

Application

Vacuum coating equipment turbine pump drive matching

Maintenance of high vacuum system for mass spectrometer

Semiconductor vacuum chamber molecular pump control

Research experiment vacuum unit renovation

Replacement of spare parts for turbo pumps in precision vacuum equipment

The LEYBOLD TURBOTRONIK NT151/361 turbo pump controller realizes the start stop speed regulation and operation status monitoring of turbo molecular pumps.

Product imag
