SODICK PIO-01 147186K Control Module Circuit Board

SODICK PIO-01 147186K Control Module Circuit Board

 Introduction

SODICK PIO-01 147186K Control Module Circuit Board

This Shadick PIO-01 147186K control module circuit board is a dedicated IO signal board for slow wire equipment, responsible for the acquisition and transmission of machine tool input and output signals.

Shadick slow wire walking equipment with IO control board

Responsible for the acquisition and output control of various switch signals of the machine tool

Onboard multiple sets of signal terminals, connecting machine tool actuators and sensors

Support high-speed signal response to ensure stable discharge machining logic

Sensitive to dust and water vapor environment, take good care of cabinet protection

When selecting, check the board identification. Different numbers cannot be directly interchanged

It is strictly prohibited to plug or unplug wiring terminals with electricity, and anti-static treatment should be done during operation

Carry out signal detection before boarding to confirm that the channel status is normal

Long term storage using anti-static packaging to maintain a dry environment

Application

Shadick slow wire equipment signal circuit matching

Transformation of Control Cabinet for CNC EDM Machine Tool

Maintenance of IO system for precision discharge machining equipment

Automated electrical discharge equipment supporting control unit

Spare parts matching for CNC machining equipment system

PIO-01 147186K control module circuit board is used for signal logic control of Shadick electrical processing equipment.

Product imag
