 Introduction

NETSTAL DIO 110.240.9216A PCB card

The NETSTAL DIO 110.240.9216A PCB card is a dedicated digital I/O board for the NEST injection molding machine system, which is used to replace commonly used industrial control spare parts for the maintenance of old models

Product Features

1 Swiss NETSTAL original digital I/O board, injection molding machine dedicated main control I/O card, is a discontinued spare part

2. Responsible for collecting and outputting switch values of the entire machine, controlling solenoid valves, safety doors, signal indicator lights, etc

3-board optoelectronic isolation, resistant to strong electromagnetic interference in injection molding workshops, improves signal stability

4-panel slot installation, matched with NETSTAL injection molding machine control system, plug and play replacement

5 compatible models in the same series: 110.240.9217D, 110.068.9056C

Integrated signal protection circuit for 6 boards, reducing the impact of external short circuits on the main control system

The 7-board comes with a status indicator light, which facilitates quick on-site troubleshooting of point signal faults

8 industrial grade PCB substrates, resistant to harsh working conditions such as high temperature and dust in the workshop

Application Areas

1. Digital signal acquisition and drive of NETSTAL horizontal injection molding machine

2. Injection molding machine safety circuit, door switch, hydraulic valve signal control

3. Equipment fault signal feedback and action interlock logic processing

4 old NETSTAL injection molding machine maintenance and replacement parts

5 Rubber molding automation production line industrial control spare parts

6. Connection of switch signal for plastic precision molding equipment

7 Injection molding unit alarm signal acquisition and output control

The supply of this board is scarce and mostly consists of disassembled spare parts. Before replacement, it is recommended to check the board number and machine program version to avoid abnormal communication on NETSTAL DIO 110.240.9216A

Product imag
