BYSTRONIC E0714-5-B Interface Module

BYSTRONIC E0714-5-B Interface Module

 Introduction

BYSTRONIC E0714-5-B Interface Module

Product Features

The IMPGEN interface board dedicated to Baichao laser machine tool is responsible for laser signal processing

The signal isolation circuit effectively resists electromagnetic interference from machine tools and ensures that the signal is not distorted

The onboard status indicator light facilitates quick troubleshooting of laser related signal faults

European style card insertion and replacement structure simplifies equipment downtime and maintenance time

Industrial grade components can withstand dust and continuous vibration environments in sheet metal workshops

Product Specifications

Model BYSTRONIC E0714-5-B

Adapt to the internal DC 24V control power supply of the machine tool

Processing laser generator feedback and command signals

Golden finger card slot installation compatible with Baichao old Poscon system

The board comes with a signal conditioning circuit to stabilize pulse signal output

Application Areas

Replacement parts for laser signal interface board of Baichao laser cutting machine

Sheet metal laser cutting equipment generator signal acquisition and processing unit

Numerical control laser equipment host and laser source signal conversion module

Interface board for the control system of Baichao CO2 laser machine tool

Laser feedback signal conditioning board for metal sheet cutting equipment

The BYSTRONIC E0714-5-B interface module is responsible for the signal interaction between the laser generator and the CNC host on the IMPGEN signal board of the Baichao laser equipment

Product imag
