Barco A505131800K5 I/O Controller Circuit Board

Barco A505131800K5 I/O Controller Circuit Board

 Introduction

Barco A505131800K5 I/O Controller Circuit Board

Product Features

The dedicated IO board for Bako projection equipment has stable signal acquisition and transmission, and is compatible with the original host

The onboard multi-channel input and output channels are responsible for the interaction of various sensor signals in the entire machine

Equipped with a built-in status indicator light, the device can quickly locate the fault location if it is abnormal

Definition of Board Interface Standard Plug and Replace Simple to Reduce Equipment Shutdown Time

Industrial grade PCB components can withstand long-term uninterrupted operation in the computer room

Product Specifications

Model Barco A505131800K5

Adapt to the internal DC 24V power supply of the device

Integrated digital input and output points

Support communication with the internal bus of the Bako main control board

Onboard hardware protection circuit prevents signal impact from damaging the board

Application Areas

Bako Large Projector Whole Machine Signal Acquisition and Control Unit

Cinema digital projector IO signal adapter replacement parts

Stage engineering projection equipment sensor signal processing board

On site signal interaction module of large screen display control system

Internal logic control board of high-end conference projection equipment

The Barco A505131800K5 I/O controller circuit board is a dedicated board for Barco projection equipment, responsible for the transmission and control of various switches and sensing signals of the equipment

Product imag
