OSAI AB OS8020Q 327051X Printed Circuit Board

OSAI AB OS8020Q 327051X Printed Circuit Board

 Introduction

OSAI AB OS8020Q 327051X Printed Circuit Board

Product Features

The motion control signal transmission of the OSAI CNC system dedicated circuit board is precise and stable

On board multi-channel signal isolation circuit reduces the impact of electromagnetic interference on machine tools

The on-site disassembly and replacement of the gold finger plug-in card structure is simple, reducing downtime

The built-in status indicator light on the board provides intuitive and convenient fault location for maintenance

Industrial grade components can withstand machine tool oil mist, dust, and continuous vibration

Product Specifications

Model OSAI AB OS8020Q 327051X

Adapt to the internal DC 24V control power supply of the device

Integrate multiple digital input and output channels

Support communication with OSAI CNC host bus

Standard European card size electrical control cabinet card slot for direct installation

Application Areas

Replacement parts for OSAI CNC equipment motion signal processing board

Signal conversion unit for control system of CNC engraving and milling machine

Woodworking CNC machining center main control signal board

IO signal processing module for stone CNC cutting machine

Multi axis CNC equipment motion control matching board

The OSAI AB OS8020Q 327051X printed circuit board is a dedicated board for OSAI multi axis CNC equipment, responsible for the interaction of equipment motion commands and on-site signals
