MOTRONA GV204 pulse separator

MOTRONA GV204 pulse separator

 Introduction

Let me introduce the MOTRONA GV204 pulse separator, which is specifically designed to process encoder pulse signals and is often used for replacing spare parts in automation equipment

Product Features

One encoder pulse signal can be divided into two independent outputs

Support signal level conversion, TTL RS422 and HTL signals switch to each other

The two output channel levels can be set separately to adapt to different receiving devices

Rail mounted, directly clamped onto the DIN rail of the control cabinet for easy disassembly and assembly

High signal transmission accuracy, small pulse delay, and no loss of position data

Product Specifications

Model MOTRONA GV204 pulse separator

Single pulse input, two pulse signal outputs

Maximum input frequency 750 kHz

Power supply range: DC 10 volts to 30 volts

Support A, B, Z incremental encoder signals

Application Areas

Signal distribution of encoder for CNC machine tools

Pulse signal diversion in motion control system

Automated production line position acquisition signal processing

Imported equipment maintenance and replacement spare parts

Signal distribution unit for servo positioning system

Overall, this MOTRONA GV204 pulse separator has stable signal splitting and flexible level conversion, which is commonly used in motion control projects

Product imag
