Nikon 4S013-374-1 Linear Motor Interface PCB

Nikon 4S013-374-1 Linear Motor Interface PCB

 Introduction

The Nikon 4S013-374-1 linear motor interface PCB is the PADATAIF-X4B signal board in the Nikon NSR lithography machine, responsible for the docking of linear motor signals.

Product Features

Stable signal transmission, suitable for high-precision motion control of lithography machines.

Equipped with signal isolation to reduce the impact of electromagnetic interference on site.

Onboard dedicated interface, directly compatible with linear motor controllers of the same series.

The process is reliable and can operate continuously in a clean workshop environment for a long time.

The board integration is high, and the rack installation and replacement are simple.

Product Specifications

Board model PADATAIF-X4B.

Compatible with NSR series lithography equipment.

Responsible for the interaction between the linear motor encoder and control signals.

The standard operating temperature range for clean workshops.

Dedicated original factory connector with fixed signal pin definitions.

Application Areas

Nikon NSR lithography machine wafer stage linear motor control.

Semiconductor lithography precision displacement servo system.

High precision mask stage motion signal acquisition.

Replacement and repair of old machine spare parts.

Semiconductor equipment second mobile phone renovation project.

This board is a key signal adapter board in the motion control of the lithography machine, which is commonly used for machine maintenance and replacement

Product imag
