 Introduction

Colleagues who maintain coating and developing equipment should have come into contact with the TEL 2985-403464-W1 pin holder station, which is a wafer support station in the TEL ACT12 track machine ADH adhesion processing unit. It relies on a top pin to lift the wafer and complete the pre-treatment process before the process.

Product Features

1. The lifting action of the top pin is smooth, and there is no easy deviation or fragmentation when lifting the wafer

2. The body is made of clean grade material, which is not easy to produce particles and meets the requirements of clean workshops

3. The mechanical structure is durable and can operate continuously for a long time, suitable for non-stop production on the production line

4. Original matching structure, perfectly matched with ACT12 rail machine, easy to disassemble and replace

5. Equipped with position feedback signal, it can transmit the workstation status to the machine control system in real time

Product Specifications

1. Compatible wafer size: 200mm

2. Supporting equipment: TEL ACT12 coating and developing track machine

3. Workstation type: ADH adhesive treatment pin bracket station

4. Cleanliness level suitable for semiconductor dust-free workshops

5. Equipped with a position sensor, it can provide feedback on the position signal of the top pin

Application Areas

1. TEL ACT12 200mm coating and developing track machine ADH process unit

2. Wafer adhesion enhancement pretreatment process

3. Wafer loading and unloading lifting positioning

4. Surface treatment of wafers before photolithography process

5. Maintenance and replacement of TEL rail machine spare parts

Overall, the TEL 2985-403464-W1 pin holder station is the core workstation of the track machine ADH module, with stable wafer support positioning and frequent maintenance and replacement of the machine.

Product imag
