ACS 1037479-000 Motion Control Module

ACS 1037479-000 Motion Control Module

 Introduction

ACS 1037479-000 Motion Control Module Product Features

Introduction: ACS 1037479-000 is a precision equipment specific motion control module responsible for multi axis servo linkage and overall motion logic control.

Modular small body, rail installation saves cabinet space

Equipped with a 20kHz high-speed servo loop, precise positioning with low jitter

Supports EtherCAT bus with minimal multi axis synchronization error

Compatible with various types of servo motors including linear, voice coil, and brushless motors

Adapt to multiple encoders including incremental, absolute, sine and cosine encoders

Built in ACSPL+language, supports custom motion programs

Comes with software PLC, capable of writing device logic programs

Equipped with smooth S-curve interpolation, running without impact or vibration

One click self-tuning of motor parameters, easy on-site debugging

Integrate multi-channel isolated IO, connect sensors and cylinders

Multiple circuit protection to prevent damage from overvoltage, overcurrent, static electricity

Metal shielding structure to resist electromagnetic interference in the workshop

Support visual location triggering and adapt to detection devices

Wide temperature stable operation, capable of 24-hour continuous operation

Standard interface specifications, easy and worry free replacement and disassembly

Conclusion: ACS 1037479-000 has strong synchronization performance and wide compatibility, and is a core motion control component for semiconductor precision equipment.

Product imag
