 Introduction

ACS CM-2-A-E-M2-H4-SC Motion Control Module Product Features

Introduction: ACS CM-2-A-E-M2-H4-SC is a 2-axis drive control integrated motion controller, suitable for high-precision precision automation equipment.

Built in dual axis drive, single axis continuous 5A, peak 10A output

Supports 85-265VAC wide voltage power supply, compatible with industrial power grids

20kHz servo closed-loop, high positioning accuracy, and low operational jitter

Compatible with brushless, linear, and voice coil servo motors

Equipped with sine cosine encoder interface, stable feedback signal

Ethernet and RS232 multiple communication interfaces, easy to connect to the upper level

Supports ACSPL+programming, with built-in simple PLC logic

High speed HSSI bus, expandable multi axis synchronous control

Equipped with S-curve interpolation, the equipment runs smoothly on and off

Equipped with multiple circuit protections for overcurrent, overvoltage, and overheating

One click self-tuning of the motor saves time and effort during on-site debugging

Metal heat dissipation shell, 24-hour continuous operation without high temperature

Standard rail installation, cabinet assembly saves space

Support location triggered collection and adapt to visual supporting equipment

Anti electromagnetic interference, suitable for dust-free semiconductor workshop working conditions

Conclusion: ACS CM-2-A-E-M2-H4-SC has high integration and stable control, and is the core unit of dual axis precision motion control.

Product imag
