 Introduction

MATROX VIP-1024A Interface Module Product Features

Introduction: MATROX VIP-1024A is a VME bus image acquisition interface board, commonly used for visual acquisition in semiconductor testing equipment.

Standard VME single slot board, easy to install and replace

Equipped with three BNC video input interfaces

Equipped with synchronous and video dual output ports

1024 × 1024 large cache, large image storage capacity

Collect and display synchronized operation without lagging

Support screen translation and scaling, flexible image processing

Equipped with pixel mask function to optimize image data

DB9 camera synchronization interface, compatible with industrial cameras

Onboard lookup table for real-time adjustment of image quality

Original components of the entire board, stable signal transmission

Multi layer precision circuit, resistant to workshop electromagnetic interference

Compatible with KLA testing equipment, strong compatibility

Low power circuit, stable long-term continuous operation

Register fast read and write, fast collection response

Industrial durable board with high adaptability to dust-free workshops

Conclusion: The MATROX VIP-1024A has a complete set of stable acquisition interfaces and is a dedicated acquisition module for semiconductor vision inspection equipment.

Product imag
