ACS CMnt2201N0N0200-ORB1 Driver

ACS CMnt2201N0N0200-ORB1 Driver

 Introduction

ACS CMnt2201N0N0200-ORB1 Driver Product Features

Introduction: ACS CMnt2201N0N0200-ORB1 is a drive control integrated EtherCAT servo drive unit, suitable for precision automation equipment, with stable comprehensive performance and adaptable to multi scene precision motion requirements.

Integrated single axis drive, compact body saves control cabinet installation space

Supports 85-230Vac wide AC power supply, compatible with general industrial power grids

Equipped with NanoPWM modulation technology, it has low motion jitter and high positioning accuracy

20kHz high-speed servo loop, fast speed and position closed-loop response

Compatible with brushless, linear, voice coil, and stepper servo motors

Multi channel encoder interface, supporting incremental, sine cosine, and absolute value feedback

EtherCAT communication cycle 2kHz, multi axis synchronization without lag

Built in STO safety torque shut-off function, ensuring safer device operation

Single axis continuous output of 7.5A, peak output of 15A, sufficient power output

Multi processor architecture, parallel processing of trajectory computation and servo control

Supporting ACSPL+programming language, supporting custom motion logic

Equipped with comprehensive fault self inspection and multiple protections for overcurrent, overvoltage, and overheating

Support one click self-tuning of motor parameters, high on-site debugging efficiency

Compatible with multiple upper level communication protocols such as Modbus and TCP/IP

Suitable for semiconductor, precision testing, and small automation platform equipment

Conclusion: ACS CMnt2201N0N0200-ORB1 combines high integration, high precision, and strong versatility, making it the preferred drive model for small space multi axis precision motion control.

Product imag
