TEL 3D80-001488-V4 Power Unit Component

TEL 3D80-001488-V4 Power Unit Component

 Introduction

TEL 3D80-001488-V4 Power Unit Component

beginning

The TEL 3D80-001488-V4 power unit component is compatible with TEL 300mm dry etching equipment and serves as the core assembly for high-power power supply of the entire machine. It has multiple stable power outputs and is suitable for all-weather continuous process operation of wafer production lines.

Equipped with Telius T-3044SS etching machine from the original factory, the electrical interface and power parameters do not require modification and can be directly installed for use

Integrated multi-channel independent power output, covering multi-level DC power supply requirements such as 5V, 12V, 24V, etc

Built in multi-level EMI filtering module, suppresses grid harmonics, does not interfere with machine sensing and communication signals

Wide range AC input design ensures stable and unbiased output voltage across all channels during voltage fluctuations in the power grid

Single channel independent current limiting and voltage stabilization protection, single branch fault does not interrupt power supply to other modules

Equipped with a surge suppression circuit, it instantly eliminates voltage surges during power on/off and protects precision board components

Multiple safety protections for the entire circuit, automatically cutting off overcurrent, overvoltage, undervoltage, and overtemperature and uploading alarms

Split type standard aviation terminal, strong and weak current circuit zoning layout, simple and clear maintenance wiring

Integrated metal enclosed heat dissipation structure ensures even heat dissipation during full load operation, reducing the probability of high-temperature shutdown

Built in real-time monitoring chip, which can provide feedback to the main control on the voltage, current, and temperature operation data of each channel

Thickened industrial PCB with three anti coating, moisture-proof and dustproof, suitable for semiconductor clean workshop working conditions

Strengthen the soldering process of electronic components, resist continuous vibration of cavity equipment, and prevent solder joints from detachment and failure

Standard rack plug-in modular structure, easy replacement and maintenance operation, reducing production line downtime

Efficient power conversion circuit, low energy loss, and controllable temperature rise of the entire machine during long-term full load operation

Lead free original factory production process, compliant with RoHS regulations, and meeting the factory compliance standards for wafer equipment

ending

The TEL 3D80-001488-V4 power unit component has stable power supply, comprehensive protection, and convenient operation and maintenance. It is the core high-power power supply assembly of the TEL 12 inch etching equipment electrical control system.
