Trenton 20-XX6901-003 Central Control Motherboard

Trenton 20-XX6901-003 Central Control Motherboard

 Introduction

Trenton 20-XX6901-003 Central Control Motherboard

beginning

Trenton 20-XX6901-003 is a long life cycle central control motherboard specifically designed for industrial equipment. It is compatible with semiconductor and automation equipment main control operations, with stable computing power and complete expansion interfaces, and can support uninterrupted production and operation of equipment 24/7.

Equipped with industrial grade Xeon multi-core processors, multi process task parallel computing without lag

Multi channel DDR3 memory slot, supports ECC error correction memory, zero error data storage

Multi channel SATA storage interface, supports dual disk backup, and securely retains production process data

Dual gigabit independent network ports, partitioned transmission of control signals and data collection, without interference with each other

PCIe 2.0 expansion slot, capable of adding motion control and acquisition cards to expand device functions

Integrated multiple serial ports and DIO digital channels for convenient integration of sensors and actuators

Customized industrial BIOS, firmware long-term stable adaptation to old equipment programs without upgrading

Onboard hardware watchdog, system freezes and automatically resets, reducing production line downtime faults

Full board multi-layer shielded wiring to resist workshop frequency converters and RF electromagnetic interference

Wide voltage stabilized power supply circuit, providing continuous and stable power supply in voltage fluctuation environment

Thickened industrial PCB substrate, combined with three anti coating, moisture-proof, dustproof, and corrosion-resistant

Reinforced plate structure, resistant to equipment operation vibration and impact, and less prone to line breakage and delamination

Real time hardware monitoring chip, synchronously collecting mainboard temperature and voltage operating parameters

Standard rack mounted installation specifications, easy disassembly and replacement, shorten equipment maintenance time

Long cycle supply design, with a lifespan of more than ten years, to ensure the long-term maintenance of equipment and the supply of accessories

ending

The Trenton 20-XX6901-003 central control motherboard balances computational performance, scalability, and industrial durability, making it the core control board for high-end automation and semiconductor equipment.

Product imag
