Fujitsu PA03585-D310 Single Board Computer Product Features

beginning

Fujitsu PA03585-D310 is a plug-in single board computer specifically designed for Fujitsu's original semiconductor equipment. It is equipped with a TEL wafer machine main control system, with stable computing and complete interfaces, and is suitable for 24/7 uninterrupted operation on production lines.

Customized embedded processors to meet the computing power requirements for semiconductor device process operations and data acquisition

Onboard multi-channel DDR memory slot, stable read and write, batch process data caching without buffering

Dual channel CF card dual storage architecture, one card system and one card storage for production logs, dual backup of data

Equipped with three independent gigabit network ports, partition transmission equipment control, screen, and data collection

Integrated DVI display output interface, directly connected to the machine operation display screen, with no delay in image output

Reserve multiple DIO digital input and output channels for docking sensors, solenoid valves, and limit components

Front mounted multiple USB expansion ports, capable of external keyboard, mouse, USB flash drive, and detection peripherals for convenient operation and maintenance

Integrated metal shielding heat dissipation cover, isolates electromagnetic interference in the workshop while balancing heat dissipation

Standard rack card insertion structure, plug-in installation, no need to disassemble the entire machine cavity for replacement and maintenance

Built in hardware watchdog circuit, automatically restarts when program freezes, avoiding production line shutdown and error reporting

Wide voltage stabilized power supply circuit, continuous and stable operation under workshop voltage fluctuation conditions

Onboard whole machine status monitoring chip, real-time reading of board temperature and voltage operating parameters

Multi layer thickened PCB substrate, resistant to equipment vibration and impact, and the circuit is not easily broken or layered

Compatible with mainstream industrial Windows embedded systems and compatible with various semiconductor process programs

Lead free original factory process, compliant with RoHS standards, meets the compliance requirements of clean semiconductor production lines

ending

Fujitsu PA03585-D310 single board computer combines computing power, expansion, and durability, making it the core computing control board for TEL semiconductor equipment.
