NSK M-EDC-PN2012AB5F7 servo drive controller

NSK M-EDC-PN2012AB5F7 servo drive controller

Product Details Introduction

NSK M-EDC-PN2012AB5F7 servo drive controller

NSK M-EDC-PN2012AB5F7 is compatible with NSK PN2012 hollow direct drive DD motor for wafer positioning station

Ultra high resolution closed-loop control, 2.62 million counts per cycle, with minimal indexing and positioning errors

Supports multiple types of upper level command inputs including pulse, serial port, and analog, and is compatible with various industrial control systems

Built in 256 sets of motion program channels, capable of pre storing multiple sets of wafer transfer process actions

Electronic gear with adjustable magnification width, multi axis synchronous linkage operation without offset

Multi channel optoelectronic isolation IO, integrated emergency stop, limit, servo enable safety signals

Equipped with multiple automatic protection mechanisms for overcurrent, overspeed, overheating, and overload

RS232 communication interface, supporting software monitoring, parameter modification, and fault reading

Internal EMC filtering to isolate workshop RF and electromagnetic signal interference

Dynamic braking function, quick locking of the turntable upon power failure to prevent wafer displacement

Ultra thin and compact body, cabinet rail installation, easy disassembly and replacement

200-230V single-phase industrial power supply, compatible with semiconductor factory distribution standards

Fast zeroing algorithm for origin, reducing the waiting time for device replacement

Dust free internal circuit, low gas release suitable for clean production workshops

Factory matched PN series motor calibration, easy debugging on the machine to put into production

Overall, the NSK M-EDC-PN2012AB5F7 servo drive controller has high positioning accuracy and large program storage capacity, making it a dedicated direct drive unit for semiconductor wafer pre alignment and rotating stage

Product imag
