TEL TTLD30-11 5880-000029-V2 Printed Circuit Board

TEL TTLD30-11 5880-000029-V2 Printed Circuit Board

Product Details Introduction

TEL TTLD30-11 5880-000029-V2 Printed Circuit Board

TEL TTLD30-11 5880-000029-V2 is used in conjunction with TEL semiconductor thin film equipment

Integrate multiple signal lines to control air valves and flow components

Onboard filtering circuit to reduce electromagnetic signal interference in the workshop

Multiple sets of IO contacts, connected to various sensing and detection components

Stable transmission rate, device instruction execution without delay

Multi layer precision circuit, signal separation is not easy to cause crosstalk

Dust free process production, meeting the standards for clean workshop use

Equipped with overcurrent and overvoltage protection circuit to reduce board damage

Standard buckle installation, easy disassembly and replacement operation

Optimized circuit layout, good heat dissipation effect and continuous operation

Stable storage circuit and retention of equipment operating process parameters

Compatible with TTLD30 module of the same series, with strong universality

Unified interface specifications, convenient and worry free wiring and assembly

Full channel factory inspection, lower machine failure rate

Simplify the board size and save installation space inside the equipment

In summary, TEL TTLD30-11 5880-000029-V2 printed circuit board has stable circuits and complete protection, making it a dedicated core circuit board for thin film process equipment

Product imag
