AMAT 0090-B1772 Control Module

AMAT 0090-B1772 Control Module

Product Details Introduction

AMAT 0090-B1772 Control Module Product Features

beginning

AMAT 0090-B1772 is a dedicated control module for ECC2 cavity of applied material semiconductor machine, which controls the temperature and pressure of wafer chuck, adsorption logic, and is compatible with Centura and Endura coating and etching equipment. The signal control is stable and reliable, and the core features are as follows:

Independent chuck dedicated computing unit, real-time control of electrostatic adsorption and temperature closed-loop

Multiple analog acquisition channels, synchronously monitoring chamber pressure, temperature, and voltage parameters

Dual industrial communication interface, connecting the main control of the whole machine with the factory MES system

Onboard storage medium, long-lasting retention of chuck process formula, no loss of power-off parameters

Built in four layers of hardware safety protection including overvoltage, overcurrent, static electricity, and overheating

Multiple sets of LED indicator lights on the panel, visually distinguishing power supply, communication, and fault status

The whole machine has a drawer style plug-in box structure, which allows for quick disassembly and replacement of cabinets and spare parts

Separate the internal circuits of strong and weak electricity to resist electromagnetic interference in clean workshops

Original factory gold-plated industrial interface, long-term repeated plugging and unplugging signal contact without attenuation

Integrated mesh hole air-cooled heat dissipation, 24-hour mass production with controllable temperature rise at full load

Three proof coating for circuit boards, resistant to dust and trace process corrosive gases

Complete fault log recording and storage, fast tracing of chuck abnormal shutdown issues

Native support for SECS/GEM protocol, compatible with fully automated smart production line docking

Standardized rack size, universal interchangeability of ECC modules starting with 0090-B in the same series

Modular split circuit, only replace local components in case of single channel failure

ending

AMAT 0090-B1772 chuck has high control accuracy and a complete protection system. It is the core original control accessory for semiconductor thin film and etching process chamber control wafer carrier.

Product imag
