AMAT 0190-32405W Controller Module

AMAT 0190-32405W Controller Module

Product Details Introduction

AMAT 0190-32405W Controller Module Product Features

beginning

AMAT 0190-32405W is a dedicated control board for semiconductor process equipment, responsible for cavity sensing, logic control of execution components, and compatible with Centura and Endura coating and etching machines. Its core features are as follows:

Multiple analog and digital signal channels, synchronously collecting pressure, temperature, and flow data

Equipped with dual industrial communication, it connects the machine master control with the factory MES system

Onboard storage chip, long-term preservation of process formula, no loss of parameters during power outage

Built in multi-layer hardware protection against overvoltage, overcurrent, and static electricity to protect precision circuits

Panel LED indicator light for intuitive recognition of operation, communication, and fault status

Standard plug-in card backplane installation, easy and effortless cabinet plugging and replacement

Isolation of strong and weak electrical lines to resist electromagnetic interference in clean workshops

Gold plated finger interface, stable signal contact after long-term repeated plugging and unplugging

Industrial wide temperature design, dust-free production line operates continuously for 24 hours without drift

Comes with a built-in fault log cache, making it easy to quickly trace device anomalies

Support SECS/GEM industrial protocol and adapt to automatic factory production line docking

Integrated heat dissipation substrate, effectively controls temperature rise during full load operation

Three proof coating circuit board, resistant to dust and slight process gas corrosion

Modular circuit layout, partial faults can be replaced with individual components

Same size and interface as the 0190 series control board, easy to exchange spare parts

ending

AMAT 0190-32405W has stable signal acquisition and comprehensive protection, and is the core original control accessory for semiconductor vacuum process chambers.
