NIKON 4S288-214-1 Controller Module

NIKON 4S288-214-1 Controller Module

Product Details Introduction

NIKON 4S288-214-1 Controller Module Product Features

NIKON 4S288-214-1 is a dedicated optical path and stage integrated control board for Nikon NSR series lithography machines. It coordinates the exposure optical path and wafer stage signal interaction, and is a core electronic control spare part for nanoscale lithography processes.

Original factory compatible with Nikon ArF/KrF immersion and dry exposure machines, standard slot direct insertion replacement without changing the wiring

Multi layer gold-plated high-density PCB, high-speed differential circuit, extremely low loss in optical servo signal transmission

Integrated multi-channel encoder acquisition channel, real-time reading of wafer stage and objective focusing position feedback

Independent optoelectronic isolation circuit, isolated from RF and vacuum pump electromagnetic signal interference in the cavity

Built in hardware filtering circuit to eliminate signal offset caused by motion jitter and light source clutter

Four layer hardware safety protection mechanism for overcurrent, short circuit, electrostatic breakdown, and overheating

Partition status indicator light, intuitive positioning of faults in optical communication, motor drive, and sensing channels

Onboard storage chip, permanently retains exposure process and stage motion parameters, and does not lose them when powered off

Standard European style gold finger slot, modular insertion and removal, time-saving and convenient cabinet disassembly and maintenance

Clean grade low expansion substrate, the circuit is not easily deformed or drifted in the temperature changing environment of the dust-free workshop

Thickened and reinforced solder pads, no virtual soldering or detachment issues during continuous reciprocating vibration of the carrier

Multi channel digital IO points, linked with vacuum suction, wafer notch detection, and shutter actuator

Low latency closed-loop signal output, fast response speed for objective focusing and stage positioning

Complete the full range calibration of the optical path and motion signal at the factory, and directly put it into mass production on the machine

Compatible with the whole machine bus communication, connected to the main control of the lithography machine to achieve remote monitoring and parameter retrieval

The NIKON 4S288-214-1 controller module is the core control unit of the lithography machine's optical path and wafer transfer system, ensuring the accuracy of etching and the stability of exposure imaging, and improving wafer production yield.
