ZYGO 8070-0902-13X laser

ZYGO 8070-0902-13X laser

Product Details Introduction

ZYGO 8070-0902-13X Laser Product Features

Introduction: ZYGO 8070-0902-13X is a ZMI series helium neon dual frequency laser head, specially designed for precision interferometric measurement, with outstanding stability and adaptability.

Using 632.8nm helium neon continuous laser with linearly polarized dual frequency output

1mW standard output power, compliant with Class II laser safety level

Excellent wavelength stability, meeting the needs of nanoscale displacement measurement

The beam pointing drift is small, and the measurement error in temperature changing environments is low

Fast preheating and light emission speed, short stabilization time, ready to use upon startup

Built in optical anti reflection design to resist interference from returning light in the optical path

Aluminum alloy lightweight body, the whole machine is lightweight and easy to install

Power supply compatible with ± 15V DC, low power consumption, controllable heating

Standard circular outgoing beam, beam diameter specifications can be matched with the system

The overall lifespan of the machine exceeds 60000 hours, with a low failure rate during long-term operation

Compatible with ZYGO interferometers and wafer inspection and measurement equipment across the entire range

Narrow frequency difference stable output, suitable for multi axis synchronous measurement scenarios

Optimization of heat dissipation structure, no performance degradation during long-term continuous operation

Standardized synchronization interface, no need to modify the docking acquisition board

Industrial wide temperature environment adaptation, workshop constant temperature equipment can be used

Conclusion: ZYGO 8070-0902-13X balances precision, durability, and versatility, and is a standard light source for semiconductor and optical testing equipment.
