Advanced Energy 3Z39-000011-V1 RF Controller

Advanced Energy 3Z39-000011-V1 RF Controller

Product Details Introduction

Advanced Energy 3Z39-00011-V1 RF Controller

Introduction: Advanced Energy 3Z39-000011-V1 is a specialized RF control unit for semiconductor process equipment, which accurately controls the RF power output and stabilizes the plasma working conditions of the cavity. Its core features are as follows:

High precision power closed-loop control, extremely low output power fluctuation, and excellent process repeatability

Built in automatic impedance matching program, quickly matching different cavity load conditions

Multiple hardware protection, automatic interlocking protection for over standing wave, over temperature, and over power

Multiple digital analog signal channels, synchronously collecting chamber pressure and power data

Standard industrial communication interface, capable of remote reading, writing, and modifying process operating parameters

Large capacity local storage, supporting one click switching of multiple etching and deposition formulas

Low harmonic RF output reduces electromagnetic interference in the workshop without affecting surrounding sensors

Independent air-cooled cooling structure, stable temperature rise during long-term full load operation without exceeding the standard

Real time fault diagnosis function, quickly locking fault codes to circuit or load abnormalities

Soft start power output to avoid instantaneous high voltage impact on precision components inside the cavity

Metal shielding shell, resistant to noise interference caused by vacuum pumps and motors

The rail type standard module structure saves time and is convenient for cabinet disassembly and maintenance

Industrial wide temperature element devices, continuous and stable operation in a dust-free workshop with constant temperature environment

Partition the wiring of strong and weak electrical lines to prevent control drift caused by signal crosstalk

Original compatible AE series RF power supply, perfectly matched with semiconductor production equipment

Conclusion: Advanced Energy 3Z39-000011-V1 has precise control and comprehensive safety protection, and is a key RF control component for thin film and etching equipment.
