ADAS 16.86021-0017 Bus Control Board

ADAS 16.86021-0017 Bus Control Board

Product Details Introduction

ADAS 16.86021-0017 Bus Control Board

ADAS 16.86021-0017 is the main control board for the industrial control system bus of printing equipment, responsible for data scheduling of the entire machine bus and collaborative control of various functional boards.

Equipped with an industrial control chip, the bus data processing speed is fast

Support dedicated industrial bus protocol, stable communication in multi board networking

Onboard optoelectronic isolation circuit effectively resists on-site electromagnetic interference

Integrated multiple hardware protection functions for overvoltage, overcurrent, and short circuit

Equipped with a running status indicator light, the fault location can be quickly identified

Standard plug-in card structure, convenient for cabinet disassembly and replacement of spare parts

Wide voltage power supply design for stable operation in fluctuating power grid environments

Wide temperature industrial materials can be used in both high and low temperature humid dust conditions

Gold plated slot pins are wear-resistant and anti-oxidation, ensuring long-lasting and reliable electrical contact

Power on automatic hardware self-test, real-time monitoring of bus link status

Flame retardant multi-layer circuit board, strong insulation, reduces short-circuit hazards

Support cascading of multiple IO and signal boards, flexible expansion of system points

Built in digital signal filtering to reduce data transmission errors caused by interference

Original precision SMT technology, earthquake and impact resistance, low operational failure rate

Perfectly compatible with ADAS series control systems, easy to debug, strong compatibility

ADAS 16.86021-0017 bus control board has stable scheduling and comprehensive protection, mainly used in printing industrial control automation equipment, and is the core control spare part of the bus system.

Product imag
