DSQC509 connector substrate unit

Product Details Introduction

The DSQC509 connector substrate unit is an I/O connection and signal adapter board inside the ABB robot control cabinet.

Brand and model: ABB DSQC509 (3HAC5687-1)

Purpose: Robot control cabinet signal connection/adapter/terminal base

Adaptation system: S4C/S4C+robot control cabinet

Power supply: 24VDC, industrial standard power supply

Interface: Integrated I/O, encoder, safety circuit and other terminals

Communication: Supports DeviceNet/fieldbus signal conversion

Installation: Installation of guide rails/racks inside the control cabinet, easy to disassemble and assemble

Status: With LED indicator light, power/communication status is intuitive

Environment: -10 ℃~+50 ℃, anti vibration and anti-interference

Structure: Compact, screw+plug-in dual connection

Safety: Integrated emergency stop, safety door and other safety signal transfer

Maintenance: Modular design, quick replacement, reduces downtime

Application: ABB robot scenarios such as automotive, welding, spraying, etc

Compatibility: Compatible with mainstream models such as IRB 140/2400/6600

Features: High reliability, easy maintenance, high integration

DSQC509 is a core I/O connection spare part for ABB robot systems, which is stable, durable, and highly adaptable.

Product imag
