COGNEX MVS-8100C Printed Circuit Board

COGNEX MVS-8100C Printed Circuit Board

Product Details Introduction

COGNEX MVS-8100C printed circuit board is a core board specifically designed for industrial machine vision by Cognex.

Adopting standard PCI bus slots, compatible with various industrial control computers

Support multi-channel analog camera signal access, compatible with black, white, and color

Capable of high-speed image acquisition to meet the requirements of online detection rhythm

Onboard independent image processing circuit with fast computation response speed

Built in external trigger interface for precise synchronized capture

Support synchronous control of strobe lights to meet on-site lighting needs

Native compatibility with VisionPro full set of visual development software

Equipped with high-precision PatMax geometric positioning algorithm

The circuit adopts industrial grade PCB board, which is resistant to electromagnetic interference

Compact board layout, saving installation space for industrial control chassis

Wide temperature working conditions, suitable for harsh production environments in workshops

Optoelectronic isolation signal design to protect equipment from surge effects

Support multi card expansion networking to achieve multi station visual inspection

Strong system compatibility, compatible with mainstream Windows operating systems

No complex configuration installation, simple and convenient debugging and maintenance

COGNEX MVS-8100C printed circuit board has strong stability and good scalability, and is widely used in machine vision scenarios such as electronic manufacturing, precision inspection, and automated production lines.

Product imag
