MECOS MBE3-50 Drive Control Magnetic Suspension Bearing System

MECOS MBE3-50 Drive Control Magnetic Suspension Bearing System

Product Details Introduction

The MECOS MBE3-50 drive control magnetic levitation bearing system is a Swiss MECOS high-performance active magnetic bearing (AMB) dedicated drive control system, focusing on high speed, frictionless, and long life, suitable for 50kW level high-speed rotating machinery.

Model: MECOS MBE3-50, active magnetic levitation bearing drive controller, 50kW power level.

Core principle: Electromagnetic force non-contact suspension, closed-loop real-time control, eliminating mechanical friction.

Power adaptation: rated at 50kW, suitable for high-speed motors, turbomachinery, compressors, etc.

Control accuracy: Micro level displacement control, stable suspension gap within ± 5 μ m.

High speed capability: Supports up to 50000+r/min, compatible with ultra high speed spindles/turbines.

Real time control: DSP+FPGA architecture, control cycle ≤ 100 μ s, fast response.

Multiple protections: overcurrent, overvoltage, short circuit, overspeed, demagnetization protection, safe and reliable.

Sensor interface: Suitable for eddy current/laser displacement sensors, high-precision position feedback.

Power consumption characteristics: No lubrication, low loss, energy-saving by 30% -50% compared to traditional bearings.

Long life design: no wear parts, MTBF≥250,000h， Maintenance free.

Operating characteristics: low vibration, low noise, speed fluctuation ≤ 0.1%.

Protective bearings: Built in backup mechanical bearings for safe landing in case of failure.

Communication interface: Supports industrial Ethernet/RS485, remote monitoring and diagnosis.

Environmental tolerance: Industrial wide temperature range, suitable for clean workshops/high humidity conditions.

Typical applications: high-speed motors, energy storage flywheels, turboblowers, molecular pumps, high-speed spindles.

Product imag
