6SC6120-0FE01 Control Module

6SC6120-0FE01 Control Module

Product Details Introduction

The 6SC6120-0FE01 control module is a Siemens SIMODRIVE 610 series single axis feed drive power board designed specifically for AC servo control. It has a compact structure, high power density, and stable and reliable operation.

Single axis AC feed drive design, compatible with SIMODRIVE 610 system, strong compatibility.

Rated current of 20A, peak current of 40A, sufficient power reserve, strong overload capacity.

Input voltage 400V AC, output 380-480V AC, compatible with industrial standard three-phase power grid.

Forced air cooling design, high heat dissipation efficiency, supports long-term continuous operation.

Industrial grade PCB power board integrated design, small size, regular wiring, and anti vibration.

Built in high-precision current/voltage sampling, precise torque/speed control, and fast dynamic response.

Improve overcurrent, overvoltage, overheating, and short-circuit protection, and achieve fast and reliable fault self diagnosis.

Suitable for high-precision positioning and speed regulation of servo motors, suitable for machine tools and automation equipment scenarios.

Modular plug-in structure, easy installation, simple maintenance and replacement, and short downtime.

Wide temperature working range, adaptable to temperature fluctuations in industrial workshops, and strong environmental adaptability.

EMC optimized design, strong electromagnetic interference resistance, suitable for complex industrial sites.

Support seamless integration with Siemens CNC systems/PLCs, with stable and efficient bus communication.

The components undergo rigorous aging screening, resulting in a low failure rate and long service life during long-term operation.

High power density, small cabinet space occupation, conducive to compact system layout.

Original Siemens process manufacturing, stable quality, suitable for new equipment matching and old system transformation.

The 6SC6120-0FE01 control module is a reliable core component for industrial servo drives, machine tool feed axis control, and other scenarios due to its high power density, strong stability, and ease of maintenance.

Product imag
