SANYO PB3A003P200 Stepper Controller

Introduction: SANYO PB3A003P200 is a SANMOTION series closed-loop stepper driver with AC input, 200W level, high precision, high response, and low vibration, suitable for small and medium-sized automated precision positioning scenarios.

Brand and model: SANYO DENKI PB3A003P200 (SANMOTION PB type)

Control method: closed-loop stepper control, built-in encoder feedback, to prevent step loss

Input power supply: AC 100-120V/200-240V wide voltage, 50/60Hz

Output power: 200W, maximum output current 3A, compatible with 42/57 closed-loop stepper motors

Command pulse: up to 250kHz, supports direction/pulse, CW/CCW commands

Communication interface: Standard RS-485, supporting Modbus for easy network control

Built in I/O: 8-way DI+8-way DO, can directly connect sensors and actuators

Control mode: position/speed/torque three modes, suitable for multiple working conditions

Protection functions: overcurrent, overvoltage, undervoltage, overheating, overload, encoder abnormal protection

Operating characteristics: high-resolution subdivision, low vibration and noise, stop and maintain torque stability

Dynamic response: Under small stroke high-frequency action, the response is better than that of servo of the same size

Structural dimensions: 200 × 125 × 99mm, metal shell, anti vibration and dustproof

Installation and maintenance: Standard rail installation, parameters can be backed up/restored with one click, easy operation and maintenance

Conclusion: PB3A003P200 is known for its closed-loop high precision, wide voltage versatility, complete protection, and easy integration. It is the preferred driving unit for small automation and precision positioning equipment.

Product imag
