STBAVO0200 Analog Output Kit

STBAVO0200 Analog Output Kit

Product Details Introduction

STBAVO0200 is a Schneider Modicon STB series standard analog output kit, including modules, bases, and connectors, used for high-precision analog control of distributed I/O systems.

1. Brand and model: Schneider Electric STBAVO0200 (kit model STBAVO0200K)

2. Equipment series: Advantys STB distributed I/O system, standard analog output kit

3. Number of channels: 2 analog outputs, capable of simultaneously controlling two field devices

4. Output type: Voltage signal, supporting multiple ranges of ± 10V, ± 5V, 0-10V, 0-5V, 1-5V

5. Resolution: 15 bits+symbol bits, high-precision output, suitable for precision control scenes

6. Supply voltage: 24V DC, logic bus current 265mA@5V  DC

7. Kit composition: STBAVO0200 module+STBXBA2000 base+STBXTS1100/2100 connector

8. Control adaptation: It can drive analog controlled devices such as frequency converters, servo drives, and regulating valves

9. Accuracy performance: Linear error ≤ ± 0.05%, low temperature drift, long-term stability

10. Protection level: IP20, dustproof and anti electric shock, suitable for installation inside control cabinets

11. Working temperature: -20 ℃~+70 ℃, suitable for wide temperature environments in industrial sites

12. Size and weight: 128.3mm × 70mm × 18.4mm, weighing approximately 0.116kg, space saving for rail installation

13. Communication compatibility: Supports PROFIBUS, Ethernet and other buses, compatible with multi network automation systems

14. Safety certification: CE, UL, CSA, FM Class 1 Division 2, compliant with industrial safety standards

15. Original quality: Made by Schneider factory, modular design, easy installation and maintenance, reliable long-term operation

The STBAVO0200 analog output kit provides precise analog output control for industrial automation with high resolution, multi range, and wide temperature stability.

Product imag
