140XBP01600 16 slot backplane

140XBP01600 16 slot backplane

Product Details Introduction

140XBP01600 is a Schneider Modicon Quantum series 16 slot high-performance backplane rack, used for the installation and interconnection of local/remote I/O, CPU, power supply, and communication modules in large and medium-sized PLC systems. It has a large capacity, stable communication, and strong redundancy.

1. Quantum series native adaptation, specifically designed for 16 slot rack installation.

2. There are a total of 16 standard slots, which can accommodate CPUs, power supplies I/O、 Communication module.

3. High speed parallel/serial hybrid backplane bus with low latency and high throughput.

4. Support local, remote, and distributed I/O, suitable for large-scale systems.

5. Integrated power distribution, supporting dual 24VDC redundant power supply.

6. Support module hot plugging, non-stop maintenance, high availability.

7. Industrial grade metal structure, resistant to vibration, impact, and electromagnetic interference.

8. Wide temperature operation from 0 ° C to 60 ° C, suitable for harsh working conditions.

9. IP20 protection, dust and foreign matter prevention, reliable installation of control cabinet.

10. Dual installation of rails and screws, compatible with standard cabinets, stable and easy to install.

11. Bus arbitration supports multiple master stations and can build redundant CPU systems.

12. Standardized interfaces, good module interchangeability, and low maintenance costs.

13. Full load heat dissipation design, stable long-term operation, and less prone to overheating.

14. Compliant with CE, UL, CSA, and IEC 61131-2 industrial certifications.

15. Suitable for large-scale automation scenarios such as power, chemical, metallurgical, and water treatment.

140XBP01600 is the core backplane of Quantum platform's large and medium-sized control systems, with 16 slots of large capacity, high-speed bus, redundant power supply, and hot swapping.

Product imag
