Product Details Introduction

140EHC20200 counter module

140EHC20200 is a Schneider Quantum series high-speed counter module designed specifically for high-frequency pulse acquisition and precise counting, suitable for motion control, speed measurement, and position feedback scenarios.

Original industrial grade module, dual independent channels, maximum counting frequency of 500kHz.

32-bit counting resolution, supporting single-phase, orthogonal A/B phase, pulse+direction and other modes.

Input compatible with 5V TTL and RS-422 differential, compatible with various encoders and sensors.

Integrate 4 FET outputs, each with 0.5A, which can directly drive loads or trigger signals.

1780Vrms isolation between channel and bus, strong anti-interference, suitable for harsh working conditions.

Configurable filtering (100ns – 10 μ s) to suppress signal jitter and ensure stable counting.

Support matching interrupt and index pulse capture, with high real-time response.

Wide temperature operation (0 ° C -+60 ° C), suitable for high temperature, humidity, and dusty environments.

Standard 140 rack installation, occupying 2 slots, easy to disassemble and maintain.

Low power design (approximately 2.5W), backplane power supply, reliable long-term operation.

Fault self diagnosis, supporting wire breakage and short circuit protection, reducing the risk of shutdown.

Compact and sturdy structure, earthquake and impact resistance, strong durability in industrial sites.

Supports incremental/orthogonal input, compatible with encoders, flow meters, and proximity switches.

Built in threshold configuration (5V/12V/24V), with wide sensor compatibility.

Widely used in high-speed precision control systems such as machine tools, packaging, textiles, metallurgy, etc.

140EHC20200 is a core module for high-frequency counting and motion control in industrial automation, with high speed precision and reliable isolation.

Product imag
