Product Details Introduction

SGMAH-02AAA21 is an Yaskawa ∑ - Ⅱ series 200W class small high-precision servo motor, suitable for single-phase AC200V power supply. It focuses on high response, low inertia, and precise positioning, and is widely used in electronic manufacturing and small automation equipment.

Rated power of 0.2kW (200W), single-phase AC200V power supply, suitable for small precision drive scenarios.

Rated speed 3000r/min, maximum speed 5000r/min, speed tolerance ± 10%.

Rated torque 0.64N · m, instantaneous maximum torque 1.92N · m, with 3 times overload capacity.

Using a 13 bit relative value serial encoder, it has high position feedback accuracy and fast response.

Permanent magnet excitation, low rotor inertia, fast dynamic response, and short positioning time.

The shaft end is a straight shaft keyless structure, with strong compatibility for installation and transmission.

No brake, no oil seal configuration, simple structure, easy maintenance.

Protection level IP55 (excluding shaft penetration), dustproof and splash proof, suitable for industrial environments.

Insulation level B, insulation resistance ≥ 10M Ω at DC500V, electrical safety and reliability.

The working temperature is 0-40 ℃, the humidity is 20-80% (without condensation), and the environmental adaptability is strong.

Flange installation, compact structure, saves installation space.

Vibration level V15, smooth operation and low noise.

Rated continuous working system to meet long-term stable operation requirements.

Compatible with Yaskawa ∑ - Ⅱ series servo drives, with high system compatibility.

Suitable for precision control scenarios such as small robotic arms, precision inspection platforms, and semiconductor equipment.

SGMAH-02AAA21 has become the 200W core execution unit in the ∑ - Ⅱ servo system due to its small size, high precision, and high response characteristics.

Product imag
