Siemens 6ES5470-8MC12 Analysis Output Module

Siemens 6ES5470-8MC12 Analysis Output Module

Product Details Introduction

Siemens 6ES5470-8MC12 Analysis Output Module

Belonging to the SIMATIC S5 series analog current output module, it provides high-precision 4-20mA signal output for industrial process control.

Compatible with PLC systems such as S5-90U/-95U/-100U, ET 100U, ET 200U, etc., with strong compatibility.

Provide 2 independent analog current output channels, with a standard range of 4-20mA, suitable for actuators such as valves and transmitters.

Adopting a floating ground/electrical isolation design, the channels are completely isolated from the system side to suppress industrial electromagnetic interference.

High output accuracy and good stability, meeting the precise adjustment requirements of flow rate, pressure, liquid level and other parameters in process control.

Powered by the backplane bus DC 24V, the maximum current consumption of a single channel is about 100mA, with low power consumption and reliable operation.

The working temperature range is * * -25 ℃~+70 ℃ * *, and the storage temperature is -40 ℃~+85 ℃, suitable for harsh industrial environments.

The protection level is IP20, and it needs to be installed inside the control cabinet to prevent dust and contact, ensuring safe operation.

The module structure is compact, weighing approximately 0.33kg, and is compatible with standard 19 inch cabinets and backplane bus installations.

Support S5 system backplane bus communication, seamless data interaction with CPU and I/O modules, and fast response.

Equipped with output short circuit and overload protection functions, it enhances the operational safety of modules and on-site equipment.

German origin, industrial grade components, high long-term stability, suitable for upgrading and maintenance of old systems.

The wiring terminal design is standardized, the wiring is simple, and it is convenient for on-site installation and later maintenance and repair.

Compliant with IEC industrial electromagnetic compatibility standards, it can stably output signals in strong interference industrial scenarios.

S5 system process control and actuator driving scenarios widely used in industries such as power, metallurgy, chemical, and manufacturing.

Siemens 6ES5470-8MC12 is a key module for analog control and execution drive in SIMATIC S5 system, thanks to its high-precision isolated output, strong anti-interference and stable adaptability.

Product imag
